Die Cast Aluminum Dimmable LED Flood Light 100w Ip65
Dimmable DALI Triac & 1-10V IK08 IP65 LED flood light 100w for
industrial light
100W New Floodlight Specification:
| Lamp power | 100w |
| Output lumen | 9700lm |
| Light efficiency | 97lm/w |
| Input voltage | AC90-305V |
| Power factor | >0.95 |
| Ip rating | IP65 |
| View angle | 120° |
| Working frequency | 50-60HZ |
| Working temperature | -20°c to +60°c |
| Cir(ra) | 67-80 |
| CCT | 2700-6500k optional |
| Warranty | 5 years |
| Heatsink material | 6063 Aluminum |
| Heat pipe material | copper |
| Reflector material | Aluminum |
| Cover material | tempered galss |
| Shell material | 6063 Aluminum |
| Bracket material | anti-corrosion steel |
| Enclosure material | stainless steel nuts & screws |
| Housing color | black |
Our Attractive Features:
1. Super bright light source---Super bright high power LED is used
as the light source with CE and RoHS approved.
2. Efficient heat-dissipation---High quality aluminum is adopted to
efficiently dissipate the heat.
3. Eco-friendly---No Pg and Hb, No pollution, No IR and UV
radiation.
4. Long life-span---The lifetime of each LED can reach over
50000hours. 2 years warranty is promised.
5. Soft and uniform light---PMMA light guiding plate is adopted to
make light softer and more uniform without flickering and glaring.
6. Pretty and solid housing---Good quality tempering glass is used
as the front cover to avoid vibration and shock. The sealed housing
is corrosion resistant sluminum with stainless steel screws.
Applications:
(1)This product is mostly applied in garment
shop,bookstore,shop,holtel,building,hotel wall,aquare night
view,landscape lighting,interior decoration,outdoor floodlight and
other places where require energy saving,green product,Low carbon
of LED light.
(2)For garden,Construction Building,Advertisement Billboard,Play
Yards
UNIQUE SPECIFICATION| ITEM CODE | DESCRIPTION | LUMEN OUTPUT | COLOUR
TEMPERATURE | CIRCUIT WATTAGE |
| LCD-FS-013-LN120 | FS 10W SMD3030 chip 120º beam | 1250lm | 3000K,4000K,6500K | 10W |
| LCD-FS-023-LN120 | FS 20W SMD3030 chip 120º beam | 2700lm | 3000K,4000K,6500K | 20W |
| LCD-FS-033-LN120 | FS 30W SMD3030 chip 120º beam | 4050lm | 3000K,4000K,6500K | 30W |
| LCD-FS-053-LN120 | FS 50W SMD3030 chip 120º beam | 6750lm | 3000K,4000K,6500K | 50W |
| LCD-FS-073-LN120 | FS 70W SMD3030 chip 120º beam | 9450lm | 3000K,4000K,6500K | 70W |
| LCD-FS-103-LN120 | FS 100W SMD3030 chip 120º beam | 14000lm | 3000K,4000K,6500K | 100W |
| LCD-FS-153-LN120 | FS 150W SMD3030 chip 120º beam | 21000lm | 3000K,4000K,6500K | 150W |
| LCD-FS-203-LN120 | FS 200W SMD3030 chip 120º beam | 28000lm | 3000K,4000K,6500K | 200W |
| LCD-FS-303-LN120 | FS 300W SMD3030 chip 120º beam | 42000lm | 3000K,4000K,6500K | 300W |
| LCD-FS-403-LN120 | FS 400W SMD3030 chip 120º beam | 56000lm | 3000K,4000K,6500K | 400W |
PRODUCT IMAGES
LINE DRAWINGS
PHOTOMETRICS (Beam patterns – Elliptical)
INSTALLATION / WARRANTY INSTRUCTIONS
