150W IP65 4000K Industrial Outdoor LED Flood Lights
Temper glass 4 mm thick diffuser IP65 LED Flood Light 150 W for
Outdoor Lighting
Product Feature:
1. Innovative Integrated Reflector
PCB is on reflector to fit tightly with aluminum shell, form an
overall integrated heat dissipation structure, so the heat
conductivity has improved greatly, which is much better to extend
service life.
2. Patented G-type Buckle Design
It is used to fix the front glass, no need any screws, makes the
outlook more beautiful and elegant
Product Specification for LED Flood Light 150W
| Item Number | 150W LCD-FLY-153 |
| LED Chip | Epistar chips or Customized |
| Lamp Hosing | Aluminum Alloy with Temper Glass |
| Housing color | Black /Sliver |
| Power | 150w |
| Input Voltage | AC100-240V |
| Lamp Efficiency | 100 Lm/W |
| Lumen | 15000 Lm |
| Light Color | Warm White, Natural White, Cool White |
| Beam Angle | 120º/50 º for option |
| Lamp Plug | Customized |
| Package | Neutral-packing or Customized |
Area & site lighting
Car parks and other areas where low mounting height poles are
installed require slim but powerful luminaires which place light
only where needed. With unique, high performance optics designed in
conjunction with Tridonic for effi ciency and
comfort, LEDFit offers excellent light control (0cd at 90°) with no
need to tilt and no compromise on product size or other performance
variables.
Standard review
IK08 IP65 Ta -25º--+50º CE RoHs SAA TUV
Power saving opportunities
FLY’s efficient LEDs combined with a long 50 000-hour lifetime
offers substantial lifetime savings and a payback period of just
one year.
Project details:
Building with Surrounds: 300m2
Energy costs: 0.12 $usd/kWh
Illuminance: 50lx
Calculation period: 15 years
Changing lamps every 2 years for the traditional/non-LED solution
LED: Cleaning the luminaires every 3 years
Operating hours: 4380 h/a
All calculations are based on an annual increase of energy and
operating costs of 5%.
Optical reflector review
Unique, high performance optics designed for efficiency and
comfort.
- True symmetric optic provides even light distribution and
excellent light control. Benefi ts include no glare or waste light,
reduced light pollution, as well as dark spot reduction.
- With high lumen output 130-150lumen/w FLY reduces the number of
luminaires required to fulfil lighting requirements and in turn
reduces lifetime costs.
- FLY offers a slim and lightweight design for ease of installation
which is unique to the market.
Product cut sheet
Product dimension review
Installation review
FLY features a super lightweight design and is pre-wired for
effortless installation.
Slim, compact and lightweight Market leading size/weight/output
ratio for high performance with low aesthetic impact.
FLY’s lean lightweight design also makes it easy to carry, install
and integrate onto existing structures.
Pre-wired. Quick and easy installation with no wiring.
Mounting options
Three mounting options to cover all low area lighting applications.
Wall or ceiliing mounted --Area & site
Surface mounted--Facade
Mast & Post--Road & Car Parking
