High Bay SMD 5050 120W Waterproof IP66 LED Flood Light
High lumen output 155lm/w Ik09 18000lm waterproof IP66 LED Flood
Light 120W
Premier LED LIGHTING
Our highbay led lighting features a 120degree beam angle that
covers more space with higher CRI and produces clearer, more color
friendly light to reduce eye strain.
Strong and Durable
This amazing CE Certified lamp features an IP65 Certified water
resistant and dustproof design, it's commercial grade, durable
properties make it the toughest and most versatile light on the
market, The pure aluminum cold forged housing provides excellent
thermal transfer to extend component life and keep it from becoming
damaged. It's operation temperature is -104 to 122 degrees
Fahrenheit.
Beautiful & Unique Design
The lightweight, low profile and circular / UFO-like design makes
this high bay light the most unique and beautiful product on the
market
1-10V Dimmable Function
HB-S3 Series LED Highbay light products come with 1-10V dimming
function. You only need to connect dimming wire with dimmer, then
you can enjoy more free space brightness.
Datasheeet
| Model | HB-S3-125 | HB-S3-155 | HB-S3-205 |
| Wattage | 120W | 150W | 200W |
| Lumen (lm) | 18000 | 22500 | 30000 |
| Rated Voltage | 90-305VAC |
| PF | >95 |
| CCT | 3000 / 4000 / 5000 / 6000K |
| CRI (Ra) | >75 |
| Waterproof | IP65 |
| LEDs | LUMILEDs |
| Driver | Meanwell/philips |
| Lifespan | >50,000hr |
| Housing Material | Aluminum |
| Operating Temperature | -30°C~ 50°C |
| Beam Angle | 60°/ 90°/ 120° |
| Warranty | 5 years |
| Certification | CE -RoHs-SAA-ETL-TUV |
Applications
・Container/ terminal lighting (High-mast lights)
・Apron floodlighting for Airport
・Car park (High-mast lights)
HB Family
| TyPE | LCD-HB-S3-055-LNXX | LCD-HB-S3-085-LNXX | LCD-HB-S3-105-LNXX | LCD-HB-S3-125-LNXX | LCD-HB-S3-155-LNXX | LCD-HB-S3-205-LNXX |
| Luminous Flux | 7,500 lm | 12,000 lm | 15,000 lm | 18,000 lm | 22,500 lm | 30,000 lm |
| Lens | 30º narrow | 30º narrow | 30º narrow | 30º narrow | 30º narrow | 30º narrow |
| Power consumption | 50W | 80W | 100W | 120W | 150W | 200W |
| Color Temperature | 3000K | 4000K | 6500K | 3000K | 4000K | 6500K |
| Color Rendering | Ra>75 | Ra>75 | Ra>75 | Ra>75 | Ra>75 | Ra>75 |
| Input Voltage | AC100-277V | AC100-277V | AC100-277V | AC100-277V | AC100-277V | AC100-277V |
| Frequency | 50-60 Hz | 50-60 Hz | 50-60 Hz | 50-60 Hz | 50-60 Hz | 50-60 Hz |
| Main Body | Aluminum Alloy | Aluminum Alloy | Aluminum Alloy | Aluminum Alloy | Aluminum Alloy | Aluminum Alloy |
| Outer lens | PC with Anti-UV & Hard-coating | PC with Anti-UV & Hard-coating | PC with Anti-UV & Hard-coating | PC with Anti-UV & Hard-coating | PC with Anti-UV & Hard-coating | PC with Anti-UV & Hard-coating |
| Exterior Painting | Heavy-duty salt resistant paint | Heavy-duty salt resistant paint | Heavy-duty salt resistant paint | Heavy-duty salt resistant paint | Heavy-duty salt resistant paint | Heavy-duty salt resistant paint |
| Mount Type | Adjustable bracket & eye bolt | Adjustable bracket & eye bolt | Adjustable bracket & eye bolt | Adjustable bracket & eye bolt | Adjustable bracket & eye bolt | Adjustable bracket & eye bolt |
| Operating Temperature | -30º--+50° | -30º--+50° | -30º--+50° | -30º--+50° | -30º--+50° | -30º--+50° |
| Rated Life (L70) | 50,000h | 50,000h | 50,000h | 50,000h | 50,000h | 50,000h |
| IK rate | IK09 | IK09 | IK09 | IK09 | IK09 | IK09 |
| Surge protection | 2-4Kv(normal mode) 10KV(on requests) | 2-4Kv(normal mode) 10KV(on requests) | 2-4Kv(normal mode) 10KV(on requests) | 2-4Kv(normal mode) 10KV(on requests) | 2-4Kv(normal mode) 10KV(on requests) | 2-4Kv(normal mode) 10KV(on requests)
|
LIGHTING PERFORMANCES
Product dimension
Installation
Packing data
