Super Slim Dimmable 100V SMD 5050 LED Flood Light 100w Ip66

    Buy cheap Super Slim Dimmable 100V SMD 5050 LED Flood Light 100w Ip66 from wholesalers

    Buy cheap Super Slim Dimmable 100V SMD 5050 LED Flood Light 100w Ip66 from wholesalers
    • Buy cheap Super Slim Dimmable 100V SMD 5050 LED Flood Light 100w Ip66 from wholesalers
    • Buy cheap Super Slim Dimmable 100V SMD 5050 LED Flood Light 100w Ip66 from wholesalers
    • Buy cheap Super Slim Dimmable 100V SMD 5050 LED Flood Light 100w Ip66 from wholesalers
    • Buy cheap Super Slim Dimmable 100V SMD 5050 LED Flood Light 100w Ip66 from wholesalers
    • Buy cheap Super Slim Dimmable 100V SMD 5050 LED Flood Light 100w Ip66 from wholesalers

    Super Slim Dimmable 100V SMD 5050 LED Flood Light 100w Ip66

    Ask Lasest Price
    Brand Name : LCD-CESP
    Model Number : LCD-HB-S3-105-LNXX
    Certification : CE RoHs SAA ETL UL TUV
    Price : usd
    Supply Ability : 5000pcs/ month
    Delivery Time : 5-12 work day
    • Product Details
    • Company Profile

    Super Slim Dimmable 100V SMD 5050 LED Flood Light 100w Ip66

    Super Slim Dimmable 100V SMD 5050 LED Flood Light 100w Ip66


    Die-cast Aluminum ADC12 housing Resistant Ik09 15000lm IP66 LED Flood Light 100W


    Product family information

    Superior light quality, long service lifetime, reduced energy consumption and less maintenance in the switch on-off (PSU) and Dali dimmable (PSD) versions, the new generation Highbay seamlessly integrates state-of-the-art LED lighting with an easy-to-use and reliable wireless ZIGBEE control solution (ACW) and simple movement detection solution (PIR). In the ACW version products, when the situation on the work floor changes, settings such as dimming levels and timing can be changed wirelessly by the end-users themselves. Luminaires can be combined in groups across the layout, and re-zoning them does not require a hardware change, thus minimizing commissioning costs. The system delivers savings over and above the actual efficiency of the LEDs and is future-proof.In the PIR version products, when there has no movement detected after 15 minutes, the lighting will dimming down to 25% of the lumen output, which helps to maximum your energy saving in a simple way. Easy to understand, easy to design-in, and easy to use, Highbay S3 is a smart way to light up your business.


    Benefits


    1. High energy saving up to 65%~88% comparing to HPI-P system
    2. Superb light quality
    3. Easy installation and maintenance
    4. Future-proof system: wireless adjustment of lighting settings and fast re-zoning if use of space changes (ACW versions)
    5. Light for need: Lighting dimming down to 25% after 15 minutes if no movement detected (PIR versions)

    Features

    1. High efficacy: 130 lumens per watt
    2. Low UGR (NB/20 ~WB/26) and accurate color (CRI> 80)
    3. Lifetime 50,000 hours with IP65 & IK07 protection
    4. Super slim design and suits for hook, pipe mounting
    5. Integrated with 1~10V PIR occupancy and movement based dimming sensor (PIR version)
    6. Integrated with ZigBee control, movement detection and day harvest sensor (ACW version)


    Applications
    ・Container/ terminal lighting (High-mast lights)
    ・Apron floodlighting for Airport
    ・Car park (High-mast lights)


    HB Family

    TyPELCD-HB-S3-055-LNXXLCD-HB-S3-085-LNXXLCD-HB-S3-105-LNXXLCD-HB-S3-125-LNXXLCD-HB-S3-155-LNXXLCD-HB-S3-205-LNXX
    Luminous Flux7,500 lm12,000 lm15,000 lm18,000 lm22,500 lm30,000 lm
    Lens30º narrow30º narrow30º narrow30º narrow30º narrow30º narrow
    Power consumption50W80W100W120W150W200W
    Color Temperature3000K4000K6500K3000K4000K6500K
    Color RenderingRa>75Ra>75Ra>75Ra>75Ra>75Ra>75
    Input VoltageAC100-277VAC100-277VAC100-277VAC100-277VAC100-277VAC100-277V
    Frequency50-60 Hz50-60 Hz50-60 Hz50-60 Hz50-60 Hz50-60 Hz
    Main BodyAluminum AlloyAluminum AlloyAluminum AlloyAluminum AlloyAluminum AlloyAluminum Alloy
    Outer lensPC with Anti-UV & Hard-coatingPC with Anti-UV & Hard-coatingPC with Anti-UV & Hard-coatingPC with Anti-UV & Hard-coatingPC with Anti-UV & Hard-coatingPC with Anti-UV & Hard-coating
    Exterior PaintingHeavy-duty salt resistant paintHeavy-duty salt resistant paintHeavy-duty salt resistant paintHeavy-duty salt resistant paintHeavy-duty salt resistant paintHeavy-duty salt resistant paint
    Mount TypeAdjustable bracket & eye boltAdjustable bracket & eye boltAdjustable bracket & eye boltAdjustable bracket & eye boltAdjustable bracket & eye boltAdjustable bracket & eye bolt
    Operating Temperature-30º--+50°-30º--+50°-30º--+50°-30º--+50°-30º--+50°-30º--+50°
    Rated Life (L70)50,000h50,000h50,000h50,000h50,000h50,000h
    IK rateIK09IK09IK09IK09IK09IK09
    Surge protection2-4Kv(normal mode) 10KV(on requests)2-4Kv(normal mode) 10KV(on requests)2-4Kv(normal mode) 10KV(on requests)2-4Kv(normal mode) 10KV(on requests)2-4Kv(normal mode) 10KV(on requests)2-4Kv(normal mode) 10KV(on requests)

    LIGHTING PERFORMANCES


    Product dimension


    Installation


    Packing data
