    Parking Lot High Power 4000K 80W IP66 LED Flood Light

    Ask Lasest Price
    Brand Name : LCD-CESP
    Model Number : LCD-HB-S3-085-LNXX
    Certification : CE RoHs SAA ETL UL TUV
    Price : usd
    Supply Ability : 5000pcs/ month
    Delivery Time : 5-12 work day
    • Product Details
    • Company Profile

    Parking Lot High Power 4000K 80W IP66 LED Flood Light

    Parking Lot High Power 12000 Lumen 80W IP66 LED Flood Light


    Die cast Aluminum alloy housing 12000 lumen waterproof IP66 LED Flood Light 80W


    Product family details


    Ambient Temperature
    • -30 to +45 °C
    Main color of the Luminaire
    • Dark gray
    Beam spread luminaire
    • 30° 60° 60° 60° 100° 120°
    Initial correlated color temperature
    • 4000K, 5000K, 6500K
    Luminous Efficiency
    • 140LM per watt
    Input frequency
    • 50 to 60 Hz
    Input voltage
    • 220-240 V
    Light source color
    • 840 neutral white, 865 cool daylight
    Material
    • Housing: aluminum die-cast
    • Cover: polycarbonate, flat
    Median Useful Life L70B50
    • 50000 h

    Looking for a low cost LED high bay?

    Well here it is! The HB-S3 is one of the brightest lights on the market today. Competitors offer similar fixtures.


    ModelLCD-HB-S3-055LCD-HB-S3-085LCD-HB-S3-105LCD-HB-S3-125LCD-HB-S3-155LCD-HB-S3-205
    Lumens7,500 lm12,000 lm15,000 lm18,000 lm22,500 lm30,000 lm
    Power50W80W100W120W150W200W
    Comparable HID or Metal Halide150W250W350W400W500W650W


    Applications
    ・Container/ terminal lighting (High-mast lights)
    ・Apron floodlighting for Airport
    ・Car park (High-mast lights)


    HB Family

    TyPELCD-HB-S3-055-LNXXLCD-HB-S3-085-LNXXLCD-HB-S3-105-LNXXLCD-HB-S3-125-LNXXLCD-HB-S3-155-LNXXLCD-HB-S3-205-LNXX
    Luminous Flux7,500 lm12,000 lm15,000 lm18,000 lm22,500 lm30,000 lm
    Lens30º narrow30º narrow30º narrow30º narrow30º narrow30º narrow
    Power consumption50W80W100W120W150W200W
    Color Temperature3000K4000K6500K3000K4000K6500K
    Color RenderingRa>75Ra>75Ra>75Ra>75Ra>75Ra>75
    Input VoltageAC100-277VAC100-277VAC100-277VAC100-277VAC100-277VAC100-277V
    Frequency50-60 Hz50-60 Hz50-60 Hz50-60 Hz50-60 Hz50-60 Hz
    Main BodyAluminum AlloyAluminum AlloyAluminum AlloyAluminum AlloyAluminum AlloyAluminum Alloy
    Outer lensPC with Anti-UV & Hard-coatingPC with Anti-UV & Hard-coatingPC with Anti-UV & Hard-coatingPC with Anti-UV & Hard-coatingPC with Anti-UV & Hard-coatingPC with Anti-UV & Hard-coating
    Exterior PaintingHeavy-duty salt resistant paintHeavy-duty salt resistant paintHeavy-duty salt resistant paintHeavy-duty salt resistant paintHeavy-duty salt resistant paintHeavy-duty salt resistant paint
    Mount TypeAdjustable bracket & eye boltAdjustable bracket & eye boltAdjustable bracket & eye boltAdjustable bracket & eye boltAdjustable bracket & eye boltAdjustable bracket & eye bolt
    Operating Temperature-30º--+50°-30º--+50°-30º--+50°-30º--+50°-30º--+50°-30º--+50°
    Rated Life (L70)50,000h50,000h50,000h50,000h50,000h50,000h
    IK rateIK09IK09IK09IK09IK09IK09
    Surge protection2-4Kv(normal mode) 10KV(on requests)2-4Kv(normal mode) 10KV(on requests)2-4Kv(normal mode) 10KV(on requests)2-4Kv(normal mode) 10KV(on requests)2-4Kv(normal mode) 10KV(on requests)2-4Kv(normal mode) 10KV(on requests)

    LIGHTING PERFORMANCES


    Product dimension


    Installation


    Packing data
