80 watt flood light led,IP67,220V,160lumen/W, 6500K,Aluminum Alloy
body,Ex light
Application
Ideal for environments with flammable gases, mists, vapors or
dusts.
• Petrochemical plants
• Chemical plants
• Pharmaceutical Factories
Gas explosive zone enviroment:
Class 1, Zone 1, Zone 2, Zone 21, Zone 22
Performance patameter
| Product type | Rated input voltage | Rated input current | Voltage frequency | Rated power | LED input current | PF | THD |
| LCD-BHD6610-50-LNXXX | 100~277VAC | 1~0.21 | 50/60Hz | 50W | 600mA | >0.98 | <10% |
| LCD-BHD6610-80-LNXXX | 100~277VAC | 1~0.32 | 50/60Hz | 80W | 600mA | >0.98 | <10% |
| LCD-BHD6610-100-LNXXX | 100~277VAC | 1.1~0.37 | 50/60Hz | 100W | 600mA | >0.98 | <10% |
| LCD-BHD6610-120-LNXXX | 100~277VAC | 1.4~0.45 | 50/60Hz | 120W | 600mA | >0.98 | <10% |
| LCD-BHD6610-150-LNXXX | 100~277VAC | 1.65~0.5 | 50/60Hz | 150W | 600mA | >0.98 | <10% |
| LCD-BHD6610-200-LNXXX | 100~277VAC | 1.9~0.85 | 50/60Hz | 200W | 600mA | >0.98 | <10% |
| LCD-BHD6610-250-LNXXX | 100~277VAC | 1.85~0.78 | 50/60Hz | 250W | 600mA | >0.98 | <10% |
Executive standard
· IEC 60079-0:2007
· IEC 60079-15:2010
· IEC 60079-31:2008
· EN 60079-0:2011
· EN 60079-15:2010
· EN 60079-31:2009
· EN 60598-1:2008+A11:2009
· EN 55015:2013
· IEC 62321:2008
Division
· ATEX Zone 2 & 22
· Class I Divison 2 GroupsA,B, C,D
· Class II Divison 2 Groups F,G
· Class III Divison 2
Certifications & Ratings
· Ex nR IIC T5 or T6 Gc
· Ex tc lllC T95ºC or T85ºC Dc IP 66
· ATEX Compliant
· ABS Compliant
· CE Compliant
· RoHS Compliant
· IP 66 Rated
General information
| Product type | Size (mm) | Weight(kg) | Ambient temp.(ºC) | Max.surface temp. ( test in 25ºC) | Temp.classification | IP code | Insulation | IK code |
| LCD-BHD6610-50-LNXXX | 330x255x166mm | 10KG | - 30ºC~+ 50ºC | 42 | T5-T6 | IP66 | I | IK09 |
| LCD-BHD6610-80-LNXXX | 330x255x166mm | 10KG | - 30ºC~+ 50ºC | 43 | T5-T6 | IP66 | I | IK09 |
| LCD-BHD6610-100-LNXXX | 330x255x166mm | 10KG | - 30ºC~+ 50ºC | 45 | T5-T6 | IP66 | I | IK09 |
| LCD-BHD6610-120-LNXXX | 446x306x166mm | 14.5KG | - 30ºC~+ 50ºC | 46 | T5-T6 | IP66 | I | IK09 |
| LCD-BHD6610-150-LNXXX | 446x306x166mm | 14.5KG | - 30ºC~+ 50ºC | 46 | T5-T6 | IP66 | I | IK09 |
| LCD-BHD6610-200-LNXXX | 446x306x166mm | 14.5KG | - 30ºC~+ 50ºC | 46 | T5-T6 | IP66 | I | IK09 |
| LCD-BHD6610-250-LNXXX | 520x360x200mm | 20.6KG | - 30ºC~+ 50ºC | 45 | T5-T6 | IP66 | I | IK09 |
| LCD-BHD6610-300-LNXXX | 520x360x200mm | 20.6KG | - 30ºC~+ 50ºC | 46 | T5-T6 | IP66 | I | IK09 |
Candela distribution
INSTALLATION METHOD
