5 Years Warranty IP66 DC12V Explosion Proof LED Flood Light
Explosion proof led light fixture 40W 130lm/w 4000K IP66 240V 5
years warranty
The main function and scope of application
The linear Ex light fitting type BHD51 is intended for use in
places with an explosive gas and dust atmosphere. The light fitting
is designed for use in the industrial areas and facilities, indoor
and outdoor spaces. Suitable for zone 2 and zone22 ; suitable for
IIA, IIB, IIC type explosive gas environment and ⅢA,ⅢB, ⅢC type
explosive dust environment; tsuitable for T6 temperature group;
environmental relative humidity: ≤ 85%; ambient temperature: -30 ℃~
+50℃; altitude ≤ 2000m; atmospheric pressure 0.8 ~ 1.1 × 105 Pa;
Widely used in oil and gas exploration, oil refining, metallurgy,
chemical, military, offshore oil platforms, oil tankers and other
dangerous places indoor and outdoor lighting.
Hazardous zones: 2, 22.
Ex batten light fitting type BHD51 is used as traditional Ex
fluorescent lighting fitting with T8 fluorescent lamps in parallel
configuration.
Technical characteristics
| Parameter | Value (unit) |
| Supply voltage | 100-240VAC 50/60Hz, |
| Apparatus category: | II 3GD |
| ATEX marking for zone 2 | II3G Ex nR IIC T6 Gc |
| ATEX marking for zone 22 | II 3D Ex tc IIIC T80 ℃ Dc IP66 |
| Certificate number | TÜV 18 ATEX 8228/IECEx TUR 18.0028 |
| Standards | EN 60079-0:2012/A11:2013; IEC60079-0:2011 Edition 6.0; EN
60079-15:2010; IEC 60079-15:2010 Edition 4.0; EN 60079-31:2014;
IEC60079-31:2013 Edition 2.0. |
| Protection class | class I (II option) |
| Ingress protection | IP 66 |
| Resistance to shock | IK09 |
| Allowable ambient temperature | T: - 30℃～+ 50℃ |
| lighting of source | LUMILEDs SMD3030 |
| Power | 10 W - 60 W |
| Cable entry | Two entries Ex e M25 & M27x1,5 for cable diameters Ø6-15 mm, |
| Through wiring | 3 x 2,5 mm2, max. 16 A,(entry and exit on one side) |
| Connecting terminals (max) | L, N, Ground - max.4 mm2 |
| Colour temperature | 4000K (optionally 3000K, 5000K, 6500K) |
| Estimated service life: | 70,000h at Tamb=40°C |
| External dimensions | 125x113x720(mm) 125x113x1020(mm) 125x113x1320(mm) |
Zones 2 & 21or 2 & 22 Linear type luminaire
LCD-BHD51 Ex LED luminaire is also intended for general lighting
industrial high bays and:
• spaces classified to zone 2,22 (optionally 21) hazardous by dust,
gas, vapour and mist of flammable
liquids explosion in temperature class up to T6
• luminaire for indoor or outdoor use
• additional spaces where occurence of high dust concentration and
water splashes are possible, such as:
boiler-rooms, wash-rooms, garrages, island station roofs,
warehouses, processing lines for chemical industry,
oil and gas industry,loose mining and building material industry
etc.
Advantages
• robust and compact design
• quick, simple and easy installation
• optional installation of lampshade on hinges during
fluorescent lamp replacement
• high resistance to a corrosive industrial environment,
• high luminous efficacy- 0.9
• high-quality ignition systems
• UV-resistant
CONSTRUCTION
LCD-BHD51 series of explosion-proof LED linear light is designed
and manufactured with a small size, light weight, long life,
pollution-free, maintenance-free, safe, energy saving, durable and
environmental-friendly Explosion-proof LED linear light.
Housing: high light transmittance PC material , the strength of more than
4J, can reduce the damage to the light in the abnormal operation.
Diffuser: PC polycarbonate plastic
Gasket(waterproof O-ring): Nitrile rubber, good aging and corrosion resistance.
Light shell: Aluminum alloy high pressure die-casting, with good
microstructure, hardness and wear resistance
Fasteners: STS304 stainless steel with high corrosion resistance and high
strength
The light fitting accessories and lamp housing split structure
design, easy installation and maintenance; selection of imported
light source chip energy saving, environmental protection, high
brightness, life expectancy up to 100,000 hours.
TECHNICAL DATA
| MODEL WATTAGE | 10/20W | 40W | 60W |
| LUMEN OUTPUT | 1300-2400 LM | 4800 LM | 7200 LM |
| DIMENSIONS | 28.3 x 4.4 x 5 in | 40 x 4.4 x 5 in | 52 x 4.4 x 5 in |
| (720 x 113 x 125 mm) | (1020 x 113 x 125 mm) | (1320 x 113 x125 mm) |
| NET FIXTURE WEIGHT (with PM type of mounting) | 7.5 lbs (3.4 kg) | 8.4 lbs (3.8 kg) | 9.25 lbs (4.2 kg) |
| ENCLOSURE MATERIAL | Copper free aluminum alloy and PC pipe |
| FINISH | High voltage electrostatic spraying surface |
| HARDWARE AND MOUNTING | Stainless steel parts and screws with high anti-corrosion
performance |
| CABLE GLANDS AND CONNECTORS | Classified for CID1 nickel plated brass adapter from Atex Ex nR M27 |
| LENS | N/A |
| LIGHT SOURCE | Lumiled 3030 |
| COLOR RENDITION INDEX (CRI) | > 80 |
| INPUT POWER (+25°C) | 20W | 40W | 60W |
| FIXTURE EFFICIENCY | 120 LPW | 120 LPW | 120 LPW |
| LED DRIVER | Lifud | Lifud | Lifud |
| 100-240VAC | 100-240VAC | 100-240VAC |
| LED DRIVER PROTECTION | Short circuit, over load protection, over voltage, open circuit
protection | Short circuit, over load protection, over voltage, open circuit
protection | Short circuit, over load protection, over voltage, open circuit
protection |
| SURGE PROTECTION | 4 kV | 4 kV | 4 kV |
| POWER FACTOR | > 0.9 | > 0.9 | > 0.9 |
| THD (total harmonic distortion) | <20% | <20% | <20% |
| INRUSH CURRENT | <60А | <60А | <60А |
| AMBIENT OPERATING TEMPERATURE | -30°C to +50°C | -30°C to +50°C | -30°C to +50°C |
| T-RATING for (+55°C) | Т6 | Т6 | T6 |
| FIXTURE LIFE (+25°C) | >50 000 hours | >50 000 hours | >50 000 hours |
| FIXTURE LIFE (+55°C) | N/A | N/A | N/A |
| FIXTURE LIFE (+65°C) | N/A | N/A | N/A |
| WARRANTY | 5 Year | 5 Years | 5 Years |
