Round Shape 60Hz Dimmable Explosion Proof LED Flood Light
Explosion proof emergency lighting 150W 240V 50/60Hz IP66 Zone 1 21
140lm/w
Features & Benefits
• 5 year full performance warranty
• L80 rated for >150,000 hours @ 25°C ambient
• Low power consumption
• Instant on/off
• Maintenance free
• Mercury free
• No UV or IR
• Resistant to shock and vibration
• Superior colour rendition index compared to HPS, LPS, MV
• Optional glass retention film available
GB Datasheet
| Product Name | ATEX Highbay |
| Shape | Round |
| Color | Grey |
| Classification | Group II Category 2GD |
| Installation(EN60079-14) | Zone 1 - Zone 2 (Gas) & Zone 21 - Zone 22 (Dust) |
| standard | IEC60079-0,IEC60079-1, EN60079-0, EN60079-1, IEC60079-28/31 |
| Ex-mark | II 2G Ex db op is IIC T4...5…T6 Gb
II 2D Ex tb op is IIIC T103°C ... T98°C ... T93°C Db |
| Rated Voltage | AC100-277V(•1) 50/60Hz |
| Housing TYPE | Φ460*243mm |
| Rated Wattage | 100W | 120W | 150W | 185W | 200W |
| Luminous FLUX | 14000lm | 16800lm | 21000lm | 25900lm | 28000lm |
| Color Temperature | 4000K, 5000K, 6500K |
| IP Grade | IP66 |
| Corrosion-proof Grade | WF2 |
| Ambient temperature | -40°C to +55°C (-40° F to 131° F) |
| Cable Entry | G3/4" or NPT 3/4" or M25x1 .5 |
| Terminals | wires<2.5mm² |
| Installation | Ceiling/pendant/bracket/wall/fence/flange |
| Remark | AC/DC 12V/24136V/48/110V are available
Emergency type is available |
Application
The GB LED High Bay luminaire was designed specifically to replace
conventional lighting in a wide variety of indoor & outdoor
hazardous
area applications. Its low profile light weight design and
versatile mounting options make it ideal for High Bay applications
for ATEX and IECEx
classified hazardous area zones. GB long life LED luminaires are
designed to meet the most demanding specification criteria while
offering maximum energy savings, reduced maintenance costs, and a
superior quality of light.
Major functions and features
• die-cast Aluminum alloy body.ADC12
• Tempered glass clear lamp housing with the features of 5J energy
impact resistance and thermal shock resistance.
• Ex "d" structure design to offer more reliable explosion proof
quality.
• Independent Exe connection cavity to improve the safety
• Specialized corrosion resistance, vibration resistance and water
& dust proof design, both indoor and outdoor application in the
harsh conditions
• High duty LED light source to ensure long life operation and
superb energy saving.
• Constant current design to guarantee the operation stability.
MECHANICAL FEATURES
Features:
- Circle shaped beam
- Precision Component
- High efficiency lighting
- Excellent luminous flux
- Made of polycarbonate with special coating treatment with Marine
grade
- Self-extinguishing UL94 guaranteed
- Vibration resistant
- Innovative design
Body: Low copper content aluminium alloy fitted with cooling fins
for better heat dissipation
Glass face: Shock and temperature resistant tempered glass sealed
with aluminium ring
Supporting bracket: Galvanised steel or stainless steel #304
Gaskets: Acid, hydrocarbon and high temperature resistant silicone
Guard(optional) Electro-polished stainless steel
Bolts and screws: Stainless steel
Entries: M25 entries (Floodlight kit with plug and cable gland on
requests)
Coating: Polyester coating Light grey
The STANDARD of the Aluminum alloy used by LCD-CESP has passed the
tests required by standards EN60068-2-30 (hot/lhumid cycles) and
EN60068-2-11 (salt mist tests)
- Service life over 60,000 hours
- Over 75% less energy consumption comparing to HID
- Easy to install low maintenance costs
- Unique horizontal tri-chamber structure
- Excellent 120° illumination
- Emergency type available battery built-in
- Zone 1, 2, 21 22
• Energy-efficient: compared with conventional lighting, LED
consumes up to 85% less energy
• Long life: last to 60,000h rated life more than, 50 times of
incandescent bulbs, 8 times of fluorescent lamps
• high light efficiency: dedicated temper glass enhance bigger
lighting area, uniform illumination
• Horizontal tri-chamber structure, ensures LED heat will not
affect driver and wiring parts.
• Optimized heat sink: aluminum housing with air diversion
structure removes heat from the LEDs and driver to ensure longer
life span
• Excellent 120° illumination, meet high illumination demand
• Wide voltage range: AC100-277V type can operate within 90-305V
range
• Multi-protection: constant current with short-circuit and
overvoltage protection
• Good EMC: excellent electromagnetic compatibility and
anti-interference
• SMT technology: surface mounting technology keeps low working
temperature of LED chip
• Standard material: copper-free Aluminum housing, surface with
epoxy powder coating, tempered glass and stainless steel external
hardware
• Emergency type: 5/10/20/30W can be battery built-in, last to
60-120 min working after power cut
LIGHT DISTRIBUTION CURVE
Dimension
Mounting
