3030 SMD Dimmable Outdoor Led Flood Light 200W IP65
Dimmable outdoor led flood light fixture 200W 1-10V dimme 240VAC
IP65 rate IK07
| Model | LCD-HQ-103 | LCD-HQ-153 | LCD-HQ-203 |
| Power | 100w | 150w | 200w |
| LED Chip | 3030 smd | 3030 smd | 3030 smd |
| Driver | MW HLG-100H | MW HLG-150H | MW HLG-240H |
| Power Factor | >0.98 | >0.98 | >0.99 |
| Voltage | AC85-265V | AC85-265V | AC85-265V |
| Warranty | 5 Years | 5 Years | 5 Years |
Product Advantages:
Excellent Light Efficiency
It is 13000Lm output, with 240lx from 10m high ceiling, 300lux from
8m height.
Modular Thermal Design
Light weight modular thermal design, light and strong, with a
minimum weight for maximum heat dissipation area.
Anodized Aluminum Body
The entire light body is anodized, no problem to be used in heavy
industrial sites and harsh environment places.
Sealed Lamp Diffuser
transparent PC light cover, flame resistant, oxidation resistance,
with silicone pad to realize dustproof, suitable for fine
processing places.
Hook and Pipe Installation
Easy and convenient installation, two ways for your option.
SPECIFICATION
| Product Number | LCD-HQ-103 | LCD-HQ-153 | LCD-HQ-203 | LCD-HQ-303 | LCD-HQ-403 | LCD-HQ-503 | LCD-HQ-603 |
| Rated Power | 100W | 150W | 200W | 300W | 400W | 500W | 600W |
| Rated Voltage | 90-305VAC |
| Lumen (lm) | 12000-13000 | 18000-19500 | 24000-26000 | 36000-39000 | 48000-52000 | 60000-65000 | 72000-78000 |
| Power Factor | >97 |
| Color Temperature | 3000-6500K |
| CRI (Ra) | >75 |
| IP Rating | IP65 |
| LED Chip & Type | LUMILEDs SMD3030 |
| LED Qty | 100pcs | 150pcs | 210pcs | 320pcs | 400pcs | 480pcs | 610pcs |
| Driver | Meanwell/philips |
| Lifespan | >50,000hr |
| Housing Material | Aluminum6063 extruded/heat copper pipe |
| Operating Temperature | -30°C~+110°C |
| Beam Angle | 25°/ 60°/ 90° |
| Warranty | 5-7 years |
LED high bay comparison
| BROWN BEAR FLOOD & HIGH BAY LCD-HQ Series | Can replace traditional metal halide | Applications |
| LCD-HQ-103 100W (13000lm) | 250w-400w | Plant construction / power plant |
| LCD-HQ-153 150W (19500lm) | 450W-600w | Workshops / factories / Automotive |
| LCD-HQ-203 200W (26000lm) | 600w-800w | Material handling / Machine building |
| LCD-HQ-303 300W (39000lm) | 800W-1200w | logistics center / warehouse |
| LCD-HQ-403 400W (52000lm) | 1200w-1600w | Smelting plant /steel mill |
| LCD-HQ-503 500W (65000lm) | 1600w-2000w | Shipbuilding / offshore platforms |
| LCD-HQ-603 600W (78000lm) | 2000w-3000w | sport court / stadium / harbor |
APPLICATIONS
| Construction and Earth Moving |
| Drilling, Mining and Quarrying |
| Demolition and Recycling |
| Transportation, Shipping and Aviation |
| Environment and Infrastructure |
| Service and Maintenance |
| Property Management |
| Forestry, Agriculture and Fur Farming |
| Rental |
| Firefighting, Rescue and Military |
| Special Vehicles and Process Industry |
| Offshore and Subsea |
