Work Site SMD3030 Bridgelux Led Industrial Flood Lights
LUMILEDs SMD3030 chip 6500K 50W Industrial LED Flood Light for work
site lighting
Specifications:
| Model Number | CCT | LED Type | Lumen(lm) | CRI | Angle(°) | Driver | Power(W)
(±10%) | Voltage
(V) | PF |
| LCD-FT-053 | 2800-3200K | Bridgelux | 110lm/W | >75 | 120 | Meanwell HLG-50H | 50Watt | AC85-265V
50/60Hz | ≥0.9 |
| 4000-4500K |
5500-6000K |
DK-HB-D005 Advantages?
1. Three View Angle
25° 60° and 100° light available, to meet every differnt project
requirement.
2. Top Quality 1060 Aluminum with 99.6% Purity
Good thermal conductivity, corrosion resistance, each aluminum fin
has hollow and groove design, reinforcing fins durability,
increasing heat dissipation area.
3. Easy Installation
With a patented hanging spares, for both pipe and hook
installation.
4. Frosted and Transparent Light Cover
Frosted cover delivers more comfortable light and low UGR, clear
cover has higher brightness.
5. Uniqu Aluminum Edging Design
Makes the aluminum heat sink more high-end and safety.
6. Excellent Light Efficiency
High power 3030 led chip is adopted, ensure high brightness, high
CRI, high color consistency.
Technical data
| Model | Power(W) | Current(A@230VAC) | IP-protection | Dimensions(mm) | Weight(KG) |
| LCD-FT-013 | 10 | 0.045 | IP65 / IK08 | 185x135x68 | 0.75 |
| LCD-FT-023 | 20 | 0.091 | IP65 / IK08 | 185x135x68 | 0.85 |
| LCD-FT-033 | 30 | 0.137 | IP65 / IK08 | 220x180x88 | 1.30 |
| LCD-FT-053 | 50 | 0.228 | IP65 / IK08 | 220x180x88 | 1.50 |
| LCD-FT-073 | 70 | 0.320 | IP65 / IK08 | 260x195x105 | 1.80 |
| LCD-FT-103 | 100 | 0.460 | IP65 / IK08 | 305x250x125 | 4.80 |
| LCD-FT-123 | 120 | 0.550 | IP65 / IK08 | 305x250x125 | 5.00 |
| LCD-FT-153 | 150 | 0.690 | IP65 / IK08 | 305x250x125 | 5.30 |
| LCD-FT-203 | 200 | 0.910 | IP65 / IK08 | 400x360x140 | 8.10 |
| illumination distribution |  |
| Product dimension |  |
installation
1. Carefully take the product out of the packaging removing any
transport safeguards.
2. The product is solely suited for installation on the wall,
ceiling and floor.
3. This product must be installed by a preofessional electrician.
4. Please make sure that the thermal management can work without
problem. Take a look at picture below.
5. Fasten the fixture to the installation place using properly
dimensioned fastening materials.
6. Connect the floodlight with a power source.
7. Check if the product functions properly and if it is securely
fixed
8. The product is now ready for operation.
| Wall mounted | Surface mounted | Ceiling mounted |
 |  |  |
III. warning
The installation should only be done by a professional electrician!
Warranty for this product is 5 years.
The warranty expires by abnormal usage, connection or change of the
structure. Damage by high voltage is not covered by the warranty:
>4kV(L,N to PE) / 2kV(L to N)
For more technical information, please contact our customer
support!
Product exploded view
