High Lumen Warm White IP65 20W Industrial Security Lights
High lumen 140lm/w IK08 waterproof IP65 20W Industrial LED Flood
Light for car parking
Product Features:
1. No noise, no flickering, anti-shock, anti-moisture.
2. Long lifespan, over 50,000 hours.
3. Compective price with high quality.
4. High lumens.
5. CE, RoHS FCC certified, 3 years warranty.
6. Eco-friendly, no pollution.
7. Turn on instantly, quick reaction.
8. High efficienency, power factor of our LED high bay is over 0.97
9. Good heat dissipation.
Datasheet of 20w floodlight
| Product Number | LCD-FT-023 | Applications |
| Rated Power | 20W |   |
| Rated Voltage | 90-305VAC |
| Lumen (lm) | 2000 |
| Power Factor | >95 |
| Color Temperature | 3000-6000K |
| CRI (Ra) | >75 |
| IP Rating | IP65 |
| LED Chip & Type | LUMILEDs SMD3030 |
| Driver | Meanwell/philips |
| Lifespan | >50,000hr |
| Housing Material | Aluminum |
| Operating Temperature | -30°C~ 50°C |
| Beam Angle | 60°/ 90°/ 120° |
| Warranty | 5 years |
| Certification | CE -RoHs-SAA-ETL-TUV
|
Our Real Promise to Customers:
◆ Reply customers no more than 12hrs.
◆ No cheat on quality.
◆ Reasonable price.
◆ Attentive after-sale service.
Feedbacks:
1. Very bright and comfortable light;
2. 60%-80% energy saving than their old light;
3. High CRI, makes all the goods looks more clean and beautiful;
4. No maintenance trouble.
Technical data
| Model | Power(W) | Current(A@230VAC) | IP-protection | Dimensions(mm) | Weight(KG) |
| LCD-FT-013 | 10 | 0.045 | IP65 / IK08 | 185x135x68 | 0.75 |
| LCD-FT-023 | 20 | 0.091 | IP65 / IK08 | 185x135x68 | 0.85 |
| LCD-FT-033 | 30 | 0.137 | IP65 / IK08 | 220x180x88 | 1.30 |
| LCD-FT-053 | 50 | 0.228 | IP65 / IK08 | 220x180x88 | 1.50 |
| LCD-FT-073 | 70 | 0.320 | IP65 / IK08 | 260x195x105 | 1.80 |
| LCD-FT-103 | 100 | 0.460 | IP65 / IK08 | 305x250x125 | 4.80 |
| LCD-FT-123 | 120 | 0.550 | IP65 / IK08 | 305x250x125 | 5.00 |
| LCD-FT-153 | 150 | 0.690 | IP65 / IK08 | 305x250x125 | 5.30 |
| LCD-FT-203 | 200 | 0.910 | IP65 / IK08 | 400x360x140 | 8.10 |
Installation
1. Carefully take the product out of the packaging removing any
transport safeguards.
2. The product is solely suited for installation on the wall,
ceiling and floor.
3. This product must be installed by a preofessional electrician.
4. Please make sure that the thermal management can work without
problem. Take a look at picture below.
5. Fasten the fixture to the installation place using properly
dimensioned fastening materials.
6. Connect the floodlight with a power source.
7. Check if the product functions properly and if it is securely
fixed
8. The product is now ready for operation.
| Wall mounted | Surface mounted | Ceiling mounted |
 |  |  |
III. warning
The installation should only be done by a professional electrician!
Warranty for this product is 5 years.
The warranty expires by abnormal usage, connection or change of the
structure. Damage by high voltage is not covered by the warranty:
>4kV(L,N to PE) / 2kV(L to N)
For more technical information, please contact our customer
support!
| illumination distribution |  |
| Product dimension |
|
Product exploded view
