High Power SMD 5050 IP65 Industrial LED Flood Lights

IP65 symmetric beam 120 degree 30W Industrial LED Flood Light for security light

LCD-FT-033 Specifications:

Our Real Promise to Customers:

◆ Reply customers no more than 12hrs.

◆ No cheat on quality.

◆ Reasonable price.

◆ Attentive after-sale service.

Biggest Advantages--Professional Structure for Heat Dissipation:

Four innovative design: copper pipe riveting technology, advanced modular heat sink, air convection design, air path optimization.

Patented heat dissipation structure is just like a 3-D highly efficient heat sink, which means more stable performance and much longer service life.

Technical data

Model	Power(W)	Current(A@230VAC)	IP-protection	Dimensions(mm)	Weight(KG)
LCD-FT-013	10	0.045	IP65 / IK08	185x135x68	0.75
LCD-FT-023	20	0.091	IP65 / IK08	185x135x68	0.85
LCD-FT-033	30	0.137	IP65 / IK08	220x180x88	1.30
LCD-FT-053	50	0.228	IP65 / IK08	220x180x88	1.50
LCD-FT-073	70	0.320	IP65 / IK08	260x195x105	1.80
LCD-FT-103	100	0.460	IP65 / IK08	305x250x125	4.80
LCD-FT-123	120	0.550	IP65 / IK08	305x250x125	5.00
LCD-FT-153	150	0.690	IP65 / IK08	305x250x125	5.30
LCD-FT-203	200	0.910	IP65 / IK08	400x360x140	8.10

illumination distribution
Product dimension

installation

1. Carefully take the product out of the packaging removing any transport safeguards.

2. The product is solely suited for installation on the wall, ceiling and floor.

3. This product must be installed by a preofessional electrician.

4. Please make sure that the thermal management can work without problem. Take a look at picture below.

5. Fasten the fixture to the installation place using properly dimensioned fastening materials.

6. Connect the floodlight with a power source.

7. Check if the product functions properly and if it is securely fixed

8. The product is now ready for operation.

Wall mounted	Surface mounted	Ceiling mounted

III. warning
The installation should only be done by a professional electrician!
Warranty for this product is 5 years.
The warranty expires by abnormal usage, connection or change of the structure. Damage by high voltage is not covered by the warranty: >4kV(L,N to PE) / 2kV(L to N)
For more technical information, please contact our customer support!

Product exploded view

LCD-CESP is the leading innovator in Lighting design.

We strive to offer the best service to our customers

Our lighting products are market leaders and have many unique features.

We offer a minimum of 5 years warranty.

Most of all Customer satisfaction is our priority.

Our R+D team have many years in the lighting Industry and we offer the following skills to our customers-

Mechanical design

Electronic design

Optic testing

We are sourcing components to the highest specification.

Our manufacturing and assembly processes are to ISO 9001 and ISO 1400 requirements.

We offer customisation and design services.
