Ex-Pendant light fittings and floodlights of the series
LCD-BHD7100-XXX
The BHD7100 series of LED pendant light fittings in IEC metallic
design is suitable for operation in hazardous areas in Zone 1/2 and
Zones 21/22, in particular in harsh environments with high
mechanical load, moisture and dust.
The lights are available in one size for 5 different wattage from
30W to 70W:
>>> The low wattage 30W to 50W version can replace for
traditional high-pressure discharge lamps from 70 W to 250 W;
>>> The high wattage 60W to 70W version can replace for
traditional high-pressure discharge lamps of 250 W and 400 W.
All versions can be operated for both Zone 1 & 21 and Zone 2 & 22
and are suitable for low and medium suspension heights.
Thanks to their high degree of ingress protection and wide
temperature range, this series can also be used under extreme
conditions.
Features
• LCD-BHD7100 pendant light fittings for Zone 1 & 21 and Zone 2 &
22 applications.
• From 30 W to 70 W and replacing traditional high-pressure
discharge lamps 70W to 400W saving power 60%- 75%.
• Wide temperature range from -30 °C up to +55 °C
• High degree of ingress protection IP66 for harsh environments
Wide range of applications
The BHD7100 lighting series is suitable for wall, ceiling and pole
mounting. This makes them the ideal solution for almost
any industrial applications, such as the illumination of open
spaces, indoor areas and roadways in industrial plants in the
oil and gas industry, chemical plants, waste disposal facilities,
shipyards, power stations and Mills.
Descriptions
- Service life over 60,000 hours
- Over 70% less energy consumption comparing to HID
- Easy to install low maintenance costs
- Unique horizontal tri-chamber structure
- Excellent 180° illumination
- Emergency type available battery built-in
- Zone 1, 2, 21 22
Features and benefits
• Energy-efficient: compared with conventional lighting, LED
consumes up to 85% less energy.
• Long life: last to 60,000h rated life o more, 50 times of
incandescent bulbs, 8 times of fluorescent lamps.
• High light efficiency: dedicated honeycomb mirror enhance bigger
lighting area, uniform illumination.
• Horizontal tri-chamber constructure, ensures LED heat will not
affect driver and wiring parts.
• Optimized heat sink: aluminum housing with air diversion
structure removes heat from the LEDs and driver to ensue longer
life.
• Excellent 180° illumination, meet high illumination demand.
• Wide voltage range: AC220V type can operate within 90-260V range.
• Multi-protection: constant current with short-circuit and
overvoltage protection.
• Good EMC: excellent electromagnetic compatibility and
anti-interference.
• SMT technology: surface mounting technology keeps low working
temperature of LED chip.
• Standard material: copper-free Aluminum housing, surface with
epoxy powder coating, tempered glass and stainless steel external
hardware.
• Emergency type: 20/30W can be battery bun, last to 60 minutes
working after power cut.
Application
Ideal for environments with flammable gases, mists, vapors or
dusts.
• Petrochemical plants
• Chemical plants
• Pharmaceutical Factories
Gas explosive zone enviroment:
Class 1, Zone 1, Zone 2, Zone 21, Zone 22
Executive standard
·IEC 60079-0:2007
·IEC 60079-15:2010
·IEC 60079-31:2008
·EN 60079-0:2011
·EN 60079-15:2010
·EN 60079-31:2009
·EN 60598-1:2008+A11:2009
·EN 55015:2013
·IEC 62321:2008
Division
·ATEX Zone 1 & 2 & 21 & 22
·Class I Divison 2 Groups A, B, C, D
·Class II Divison 2 Groups F,G
·Class III Divison 2
Certifications & Ratings
·Exd IIC T6 Gb
·Ex tD A 21 IP66 T80ºC
·ATEX Compliant
·ABS Compliant
·CE Compliant
·RoHS Compliant
·IP 66 Rated
Characteristic details
Performance patameter
| Product type | Rated input voltage | Rated input current | Voltage frequency | Rated power | LED input current | PF | THD |
| LCD-BHD7100-30 | 90~264VAC | 1~0.21 | 50/60Hz | 30W | 600mA | >0.95 | <15% |
| LCD-BHD7100-40 | 90~264VAC | 1~0.32 | 50/60Hz | 40W | 600mA | >0.95 | <15% |
| LCD-BHD7100-50 | 90~264VAC | 1.1~0.37 | 50/60Hz | 50W | 600mA | >0.95 | <15% |
| LCD-BHD7100-60 | 90~264VAC | 1.4~0.45 | 50/60Hz | 60W | 600mA | >0.95 | <15% |
| LCD-BHD7100-70 | 90~264VAC | 1.65~0.5 | 50/60Hz | 70W | 600mA | >0.95 | <15% |
Photometric parameters
| Optical data |
| Product type | Color temp. | CRI | CCT(K) | luminous flux(lm) | Beam angle(°) |
| LCD-BHD7100-30 | warm / Neutral / cool | 83/80/72 | 3000k / 4000K / 6500K | 3300 | 180° |
| LCD-BHD7100-40 | warm / Neutral / cool | 83/80/72 | 3000k / 4000K / 6500K | 4400 | 180° |
| LCD-BHD7100-50 | warm / Neutral / cool | 83/80/72 | 3000k / 4000K / 6500K | 5500 | 180° |
| LCD-BHD7100-60 | warm / Neutral / cool | 83/80/72 | 3000k / 4000K / 6500K | 6600 | 180° |
| LCD-BHD7100-70 | warm / Neutral / cool | 83/80/72 | 3000k / 4000K / 6500K | 7700 | 180° |
General information
| Product type | Size (mm) | Weight(kg) | Ambient temp.(ºC) | Max.surface temp. ( test in 25ºC) | Temp.classification | IP code | Insulation | IK code |
| LCD-BHD7100-30 | ¢210x345mm | 6KG | - 30ºC~+ 50ºC | 34 | T6 | IP66 | I | IK08 |
| LCD-BHD7100-40 | ¢210x345mm | 6KG | - 30ºC~+ 50ºC | 35 | T6 | IP66 | I | IK08 |
| LCD-BHD7100-50 | ¢210x345mm | 6KG | - 30ºC~+ 50ºC | 40 | T6 | IP66 | I | IK08 |
| LCD-BHD7100-60 | ¢210x345mm | 6KG | - 30ºC~+ 50ºC | 42 | T6 | IP66 | I | IK08 |
| LCD-BHD7100-70 | ¢210x345mm | 6KG | - 30ºC~+ 50ºC | 44 | T6 | IP66 | I | IK08 |
Candela distribution
Products Dimension
INSTALLATION METHOD
