Vapour proof led lights 120W die-cast Aluminum 240V 50/60Hz IP66
140lm/w IK09
GB LED Explosion-Proof High Bay Luminaire
The GB is a robust and reliable LED High Bay Luminaire for use in
oil & gas, petro-chemical, aviation, marine and utility
applications.
Suitable for use in Zones 1,2,21 & 22, weatherproof to IP66 and
with a robust LM6 alloy housing, the GB is suitable for use in the
harshest environments.
Utilising LED light engines, the GB provides excellent illumination
while running very cool to ensure high reliability and long life.
GB High Bay Luminaires are fitted with our own custom built driver
which ensures the driver lasts as long as the LED and is more
suited to the extremes of temperature encountered in an
explosion-proof application.
Features
- ATEX/IECEx approved for use in Zones 1, 2, 21 and 22
- Lightweight, robust and vibration resistant design
- High Light output, 12000 lm
- High power 100~ 240w
- Robust, marine grade corrosion resistant alloy enclosure
- Universal 90V to 264V ac voltage range
Technical
| Name | Explosion proof Light 120W |
| Wattage | 120W |
| Luminous Flux | 12000lm |
| Light source | 3030 SMD LED |
| Input Voltage | 100-277VAC |
| Lumen | 100lm/w |
| Cetification | UL844, ATEX, IECEX |
| Model Number | GB-01-120 |
| Colour Temperature | 4000K, 5000K, 6500K |
| Power Factor | >0.95 |
| Beam Angle | 120° |
| Color Rendering Index (CRI) | >75 |
| LED Emitter Life | 50,000 hours |
| Operating Temperature | -40°C ~ 55°C |
| IP rate | IP66 |
| Warranty | 5 years |
MECHANICAL FEATURES
- Circle shaped beam
- Precision Component
- High efficiency lighting
- Excellent luminous flux
- Made of polycarbonate with special coating treatment with Marine
grade
- Self-extinguishing UL94 guaranteed
- Vibration resistant
- Innovative design
Body: Low copper content aluminium alloy fitted with cooling fins
for better heat dissipation
Glass face: Shock and temperature resistant tempered glass sealed
with aluminium ring
Supporting bracket: Galvanised steel or stainless steel #304
Gaskets: Acid, hydrocarbon and high temperature resistant silicone
Guard(optional) Electro-polished stainless steel
Bolts and screws: Stainless steel
Entries: M25 entries (Floodlight kit with plug and cable gland on
requests)
Coating: Polyester coating Light grey
The STANDARD of the Aluminum alloy used by LCD-CESP has passed the
tests required by standards EN60068-2-30 (hot/lhumid cycles) and
EN60068-2-11 (salt mist tests)
- Service life over 60,000 hours
- Over 75% less energy consumption comparing to HID
- Easy to install low maintenance costs
- Unique horizontal tri-chamber structure
- Excellent 120° illumination
- Emergency type available battery built-in
- Zone 1, 2, 21 22
• Energy-efficient: compared with conventional lighting, LED
consumes up to 85% less energy
• Long life: last to 60,000h rated life more than, 50 times of
incandescent bulbs, 8 times of fluorescent lamps
• high light efficiency: dedicated temper glass enhance bigger
lighting area, uniform illumination
• Horizontal tri-chamber structure, ensures LED heat will not
affect driver and wiring parts.
• Optimized heat sink: aluminum housing with air diversion
structure removes heat from the LEDs and driver to ensure longer
life span
• Excellent 120° illumination, meet high illumination demand
• Wide voltage range: AC100-277V type can operate within 90-305V
range
• Multi-protection: constant current with short-circuit and
overvoltage protection
• Good EMC: excellent electromagnetic compatibility and
anti-interference
• SMT technology: surface mounting technology keeps low working
temperature of LED chip
• Standard material: copper-free Aluminum housing, surface with
epoxy powder coating, tempered glass and stainless steel external
hardware
• Emergency type: 5/10/20/30W can be battery built-in, last to
60-120 min working after power cut
Full Range
| Classification | Group II Category 2GD |
| Installation(EN60079-14) | Zone 1 - Zone 2 (Gas) & Zone 21 - Zone 22 (Dust) |
| standard | IEC60079-0,IEC60079-1, EN60079-0, EN60079-1, IEC60079-28/31 |
| Ex-mark | II 2G Ex db op is IIC T4...5…T6 Gb II 2D Ex tb op is IIIC T103°C
... T98°C ... T93°C Db |
| Rated Voltage | AC100-277V(•1) 50/60Hz |
| Housing TYPE | Φ460*243mm |
| Rated Wattage | 100W | 120W | 150W | 185W | 200W |
| Luminous FLUX | 14000lm | 16800lm | 21000lm | 25900lm | 28000lm |
| Color Temperature | 3000K, 4000K, 6500K |
| IP Grade | IP66 |
| Corrosion-proof Grade | WF2 |
| Ambient temperature | -40°C to +55°C (-40° F to 131° F) |
| Cable Entry | G3/4" or NPT 3/4" or M25x1 .5 |
| Terminals | wires<2.5mm² |
| Installation | Ceiling/pendant/bracket/wall/fence/flange |
| Remark | AC/DC 12V/24136V/48/110V are available Emergency type is available |
LIGHT DISTRIBUTION CURVE
Mounting
