Parking Lot IP 66 350W Cool White High Lumen LED Flood Light

KEY Advantages
• Designed to operate LED light sources of up to 350W in an ambient temperature (Tq) environment of up to 25˚C, without
reducing the useful lifetime of 100 000 hours, at a lumen depreciation of not more than 30% (L70).
• Easy to install and different applications
• No lamp or component replacements for more than 5-7 years
• Designed for easy technology upgrade for future.
• Marine grade, high-pressure die-cast aluminium housing
• Designed to replace conventional HID and CFL streetlight and floodlight luminaires (up to 1500W HPS) with energy savings up to 75%
• One-compartment housing, ensures reliable ingress protection
• Surge protection 10kV/10kA on requests

Characteristics---LUMINAIRE

Optical compartment tightness level : >>>>>>> IP 66
Control gear tightness level : >>>>>>>>>>>>>>IP 66
Impact resistance (glass) : >>>>>>>>>>>>>>>>IK 08
Input voltage : >>>>>>>>>>>>>>>>>>>>>>>>>85-265VAC - 50/60Hz
Electrical class : >>>>>>>>>>>>>>>>>>>>>>> I
Operating temperature (Ta) : >>>>>>>>>>>>>>-30˚C>Ta ≤+50˚C
Weight (total) : Midi>>>>>>>>>>>>>>>>>>>>>>2.9kg Maxi>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>9.3kg
Correlated colour temperature (CCT) : >>>>>>> warm white Neutral white,cool white(2700-6500K, CRI ≥70)
Materials: Body : >>>>>>>>>>>>>>>>>>>>>>> Marine grade aluminium(EN 1706 AC-44300)
Protector : >>>>>>>>>>>>>>>>>>>>>>>>>>>>High-impact clear glass and polycarbonate lens
Installation height:

Midi: up to 15m
Maxi: up to 30m
Aerodynamic resistance (CxS):
Midi: 0.015m²
Maxi: 0.027m²
Standard finish: black corrosion resistant powder coating Aluminium

Smart Spigot™ Kit The bottom-entry mounting Spigot™ kit is manufactured from ¢60mmx182mm die-cast aluminum alloy.
Options • Incorporated downward facing daylight switch on requests. • Pre-programmable stand-alone dimming on requests. • Surge protection up to 3-4KV and 10-20kV on requests • Protector made of impact-resistant material. • Vandal-resistant version on requests • Aluminum alloy Spigot kit

Application

Products Dimensions in MM

Candela distribution
