Super Bright Aluminum 24v High Power LED Street Light 100W
Key Features and benefits
- Very bright and comfortable light
- 60%-80% energy saving than conventional light source, save a lot of
electricity bill
- High CRI, makes all the goods looks more clean and beautiful
- No maintenance trouble
- Consists of LED engine + LED Driver + spigot kit
- Easy installation
- Rated IP 66
- The power supply is disengaged when opening the luminaire
- The luminaire housing is manufactured of marine grade aluminium
- Designed for LED light sources between 80W and 350W
- The power factor is rated at ≥0.97 and high lumen output up to
175lumen/w
Mechanics
| Electronic control Gear | Meanwell or Philips Constant Current Driver IP 67 |
| Materials and finishing | Housing – Aluminium Alloy Protector – High-impact clear glass (IK 08) or and polycarbonate
lens |
| Coating | Black and RAL colours on request |
| Installation | Bottom-entry mounting spigot™ kit |
| Fixing | ø60-65 Fixing holes |
| Dimensions (LxWxH) | Maxi – 545.6 x 447.1 x 64.8 mm Midi – 274 x 299.6 x 51.8 mm |
| Weight (with gear) | Maxi – 9.3 kg Midi – 2.9 kg |
| Access | Yes |
| Aerodynamic resistance (CxS): | Maxi – 0.027m2 Midi – 0.015m2 |
Electrical Characteristics
| Line Voltage | 220VAC |
| Mains voltage Tolerance (AC) | 85-265V |
| Line frequency | 50/60Hz |
| Electrical Safety Class (IEC) | Class I |
| Surge protection | Yes - 3-4KV (10kV/10kA on requests) |
| Lighting control | -on requuests below - Incorporated downward facing daylight switch - Pre-programmable stand-alone dimming - Solar version for Midi is available |
Power supply
| Power Factor | ≥0.97 |
| Removable | Yes |
| Thermal Safety | Yes |
Environment
| Storage temperature | -40< T < 85 |
| Enclosure Tightness | IP 66 |
| Enclosure Mechanical Withstand Impact | IK 08 |
| Enclosure Mechanical Withstand Vibrations | Modified IEC 60068-2-6 |
Application
| • Façade lighting | • Area lighting |
| • Security lighting | • General floodlighting |
| • Car parking lighting | • General street lighting |
Products Dimensions in MM
FAQ
1. What 's your payment method?
In general,we use Paypal and Western Union for the total order less
than US$ 500 in order to reduce the extra fee, Bank Tranfer payment
can be accepted for large order too.
2. How long will it take to execute my order ?
This depends on the order quantity.Our nornal delivery time is 5-7
working days.
3. How much will the shipping charges be ?
This will depend on the size of your shipment and the method of
shipping.Whe inquiriedabout shipping charges,we hope that you let
us know the detailed information such as the post code and quantity
,your favorable method of shipping (by air or by sea ) and your
designated port or airport.
4. Do you provide samples ?
Yes ,we can provide samples of all the items listed.In general of
facture rule, the sample cost and shipping cost will be in buyer
side.We can send the sample by DHL,FEDEX,EMS and UPS .
5. Do you have products in stock?
For most common items we have stock but we could not reserve all
the items in stock.Ifthere is any in stock,we will inform you with
details.
6. What the warranty term for your products?
All of our products have at least one year warranty in normal use.
Please provide or video ia any quality problem during this
period.We will replace a new one to you in thenext order.
7. Can I visit you?
Sure, please let us know if you wanna visit our factory ,we will
arrange it for you.
8. Do I need to send the defective products back to you for
warranty.
No,you don’t need to send it back for warranty for the defective
products.If any damage happens not caused by misure or
vandalism,then we ‘ll send you a new one.
