Outdoor LED SMD Flood Light
UV protected polycarbonate lens 60 degree 30W LED SMD Flood Light
for outdoor lighting
Product data
Eagle FS series is designed to meet the requirements of a wide
range of floodlighting applications such as public area
lighting,car parking,billboard,security,work site etc. FS Flood
makes sure you can choose the exact number of fixtures you need for
your application. Incorporating extremely high-efficiency optics
and LEDs LUMILEDs & OSRAM chip and Meanwell driver, you get a
highly competitive solution offering an outstanding lux/usd dollar
ratio and energy savings of up to 75%. Those range choice of optics
ensures maximum application coverage. FS Flood is really easy to
install − you simply plug it in and select the best option for your
needs. Perfect for replacing traditional lamp meanwhile saving
money and saving time.
General Information
Lamp family code : LCD-FS-033 / 035 [ 4050 lm to 4800 lm]
Light source color : warm white 3000K , neutral white 4000K , cool
white 6000K
Light source & lens replaceable : Yes [LUMILEDs , Cree , Bridgelux
, OSRAMs / different optic lens ]
Number of gear : one bracket
Driver/power : Meanwell driver Or LCD brand driver
Optical cover type : 4mm thick Flat temper glass
Luminaire light beam spread : 15° , 25°, 30°, 60° , 90°, 120° ,
TYPE I , TYPE II , TYPE III , TYPE IV , TPYE V , Asymmetric 45°
Protection class : IEC Safety class I
CE mark : CE mark
Warranty period 5 years
Optic type : outdoor & indoor Symmetrical & Asymmetrical
RoHS mark : RoHS mark
Light source engine type : LED
FS Family
| Item | 10W | 20W | 30W | 50W | 80W | 100W | 150W | 200W |
| Input Voltage | 90-265VAC or 12-28VDC |
| Input Current | 0.05A | 0.1A | 0.15A | 0.23A | 0.38A | 0.48A | 0.7A | 0.93A |
| Power Efficiency | >89% | >89% | >89% | >95% | >97% | >97% | >97% | >97% |
| LED Consumption | 9W | 18W | 27W | 45W | 72W | 91W | 135W | 185W |
| System Consumption | 10W | 20W | 30W | 50W | 80W | 100W | 150W | 200W |
| Power Factor | >0.95 |
| Total Harmonic Distortion | THD< 20% |
| Dimmable | 1-10V , DALI ,Triac on requests |
| Power Line | 1.0m㎡three line |
| Chip Brand | LUMILEDs/CREE/Bridgelux / OSRAM (SMD3030) / SMD5050 on requests |
| LED Encapsulation | 12LEDs | 24LEDs | 36LEDs | 60LEDs | 96LEDs | 120LEDs | 180LEDs | 240LEDs |
| Rated LED Efficacy | 160-180 lumen/w |
| Luminous Efficiency | 130-160 lumen/w |
| Color Temperature | 3000K / 4000K / 6500K |
| Luminous Output (Typ.) | 1350lm | 2700lm | 4050lm | 6750lm | 10800lm | 13500lm | 20250lm | 27000lm |
| CRI | Ra> 80 |
| SCDM | SDCM <5 |
| Lumen Maintenance | > 80%@50,000h
|
Operating and Electrical
Input Voltage 100 to 277 VAC or 12-28 VDC
Input Frequency 50 to 60 Hz
Inrush current 340 A
Inrush time 0.025 ms
Power Factor (Min) >0.95
Controls and Dimming
Dimmable on requests 1-10V , DALI , Triac
Mechanical and Housing
Housing Material Aluminum die-cast 6063
Reflector material Polish Aluminum
Optic material Acrylate
Optical cover 4mm temper Glass
Fixation material corrosion resistant powder coating carbon Steel
Mounting device Mounting bracket adjustable
Optical cover Flat
Optical cover Clear
Approval and Application
Ingress protection code IP65 [ Dust penetration-protected,
jet-proof]
Mech. impact protection code IK08 [ 5 J vandal-protected]
Surge Protection Luminaire surge protection level >2 kV
Initial Performance (IEC Compliant)
Initial luminous flux (system flux) 3900-4800 lm
Luminous flux tolerance +/-6%
Initial LED luminaire efficacy 130-160 lm/W
Init. Corr. Color Temperature 3000K 4000 K 6500K
Init. Color Rendering Index ≥75
Initial chromaticity (0.380, 0.390) SDCM <5
Initial input power 30 W
Power consumption tolerance +/-10%
Product cut sheet
Over Time Performance (IEC Compliant)
Driver failure rate at 7000 h 0.5 %
Useful life L80B10 100000 h
Lumen maintenance at useful life of 100000 h,at 25 °C
93
Application Conditions
Ambient temperature range -30 to +45 °C
Dimensional drawing
Installation & Mounted and package list
Photometric data
