UV Protected Waterproof Ip65 IK08 150w LED SMD Flood Light

Power Efficiency >90% waterproof IP65 IK08 150W LED SMD Flood Light for 5 years warranty

What is led flood lights?
LED flood light is a point light source that can illuminate evenly in all directions. Its irradiation range can be adjusted arbitrarily.LED Flood Light is designed for outdoor and indoor lighting purpose,and most of them are usually use of high-powered light sources to illuminate a large outdoor space.It’s an ideal replacement for traditional MH/HPS lamps to cut down energy consumption and improve lighting performance,and helps to improve visibility and enhance safety.There are three main types of flood lighting applications: facade, sign, and general area. For example,use LED flood light to accentuate the architectural features of a historical or impressive building.The other is general safety area lighting for sporting events.These type of LED flood lights are usually installed at a higher position to illuminate a larger area.All in all,almost all large-area lighting fixtures used outdoors can be regarded as LED floodlights.

150w floodlight for Billboard

Leading LCD improves visibility on signage, More than 80% energy saving, maximum lights are directed to their targets, Excellent uniformity, no dark areas among lights.
• Advanced design enables the easiest installation ever
• High thermal conductive and corrosion-resistant design
• IP65 & IK 10

Specification

Rated Wattage: 100Watt / 150W / 200W
Rated Voltage: 100-277Vac, 50/60Hz
Luminaire Efficacy: 130lm/W
Lumen Output: 1,300lm-5,460lm
CCT: 5000K (3000K/4000K Optional)
CRI: Ra75 (≥Ra85 optional)
Applications: For billboard lighting applications,such as panel boards and poster boards.

Certification

CE, ROHS

Controls and Dimming
Dimmable on requests 1-10V , DALI , Triac

FS Family

Mechanical and Housing
Housing Material Aluminum die-cast 6063
Reflector material Polish Aluminum
Optic material Acrylate
Optical cover 4mm temper Glass
Fixation material corrosion resistant powder coating carbon Steel
Mounting device Mounting bracket adjustable
Optical cover Flat
Optical cover Clear

​
Approval and Application
Ingress protection code IP65 [ Dust penetration-protected, jet-proof]
Mech. impact protection code IK08 [ 5 J vandal-protected]
Surge Protection Luminaire surge protection level >2 kV

Initial Performance (IEC Compliant)
Initial luminous flux (system flux) 21750-23250 lm
Luminous flux tolerance +/-6%
Initial LED luminaire efficacy 130-160 lm/W
Init. Corr. Color Temperature 3000K 4000 K 6500K
Init. Color Rendering Index ≥75
Initial chromaticity (0.380, 0.390) SDCM <5
Initial input power 150 W
Power consumption tolerance +/-10%

Product cut sheet

Over Time Performance (IEC Compliant)
Driver failure rate at 7000 h 0.5 %
Useful life L80B10 100000 h
Lumen maintenance at useful life of 100000 h,at 25 °C
Application Conditions
Ambient temperature range -30 to +45 °C

Dimensional drawing

Installation & Mounted and package list

Photometric data

LCD-CESP is the leading innovator in Lighting design.

We strive to offer the best service to our customers

Our lighting products are market leaders and have many unique features.

We offer a minimum of 5 years warranty.

Most of all Customer satisfaction is our priority.

Our R+D team have many years in the lighting Industry and we offer the following skills to our customers-

Mechanical design

Electronic design

Optic testing

We are sourcing components to the highest specification.

Our manufacturing and assembly processes are to ISO 9001 and ISO 1400 requirements.

We offer customisation and design services.
