Waterproof 30 Degree 80W Outdoor Led Flood Light Fixtures
high lumen 150lm/w waterproof IP65 80W symmetric 30 degree LED SMD
Flood Light
FLOOD LIGHTS
If you’re looking for high quality yet competitively priced
exterior LED flood lights solution for your commercial or
industrial business, then look no further. We offer a wide range of
high-end outdoor flood light fixtures in a range of brands and
models in wattages of 10W, 30W, 50W, 70W, 100W, 150W, 300W LED
flood lights and all the way up to 600W. We are here to help you
pick the right model to suit the lighting requirements of your
project.
Our selection of exterior LED flood lights, RGB LED flood lights,
low profile LED flood lights and low voltage LED flood lights have
been designed with durability in mind. Most of our models offer a
selection of lumen outputs, colour temperatures in 3000K, 4000K,
5000K, 6500K and protection ratings from IP65 to IP68. Security
flood lights are used in a wide range of applications such as
sports lighting and area lighting.
Econ LED Flood Light
Cost-effective, versatile, and durable, LCD LED Flood Light is born
to be a desirable lighting solution for most outdoor and indoor
applications. With 140lm/W efficacy and 9 beam angles for option,
you can always count on Econ for enhanced visibility.
• 9 beam angles
• Well-shaped with great aesthetic feeling
• Die casting design with perfect cooling performance
Input:100 to 277 VAC or 12-28 VDC
Frequency:50 to 60 Hz
Inrush current :340 A
Inrush time:0.025 ms
PF:>0.95
Dimmable:1-10V , DALI , Triac
FS Family
| Item | 10W | 20W | 30W | 50W | 80W | 100W | 150W | 200W |
| Input Voltage | 90-265VAC or 12-28VDC |
| Input Current | 0.05A | 0.1A | 0.15A | 0.23A | 0.38A | 0.48A | 0.7A | 0.93A |
| Power Efficiency | >89% | >89% | >89% | >95% | >97% | >97% | >97% | >97% |
| LED Consumption | 9W | 18W | 27W | 45W | 72W | 91W | 135W | 185W |
| System Consumption | 10W | 20W | 30W | 50W | 80W | 100W | 150W | 200W |
| Power Factor | >0.95 |
| Total Harmonic Distortion | THD< 20% |
| Dimmable | 1-10V , DALI ,Triac on requests |
| Power Line | 1.0m㎡three line |
| Chip Brand | LUMILEDs/CREE/Bridgelux / OSRAM (SMD3030) / SMD5050 on requests |
| LED Encapsulation | 12LEDs | 24LEDs | 36LEDs | 60LEDs | 96LEDs | 120LEDs | 180LEDs | 240LEDs |
| Rated LED Efficacy | 160-180 lumen/w |
| Luminous Efficiency | 130-160 lumen/w |
| Color Temperature | 3000K / 4000K / 6500K |
| Luminous Output (Typ.) | 1350lm | 2700lm | 4050lm | 6750lm | 10800lm | 13500lm | 20250lm | 27000lm |
| CRI | Ra> 80 |
| SCDM | SDCM <5 |
| Lumen Maintenance | > 80%@50,000h
|
Mechanical and Housing
Housing Material Aluminum die-cast 6063
Reflector material Polish Aluminum
Optic material Acrylate
Optical cover 4mm temper Glass
Fixation material corrosion resistant powder coating carbon Steel
Mounting device Mounting bracket adjustable
Optical cover Flat
Optical cover Clear
Approval and Application
Ingress protection code IP65 [ Dust penetration-protected,
jet-proof]
Mech. impact protection code IK08 [ 5 J vandal-protected]
Surge Protection Luminaire surge protection level >2 kV
Initial Performance (IEC Compliant)
Initial luminous flux (system flux) 10800-12000 lm
Luminous flux tolerance +/-6%
Initial LED luminaire efficacy 130-160 lm/W
Init. Corr. Color Temperature 3000K 4000 K 6500K
Init. Color Rendering Index ≥75
Initial chromaticity (0.380, 0.390) SDCM <5
Initial input power 80 W
Power consumption tolerance +/-10%
Over Time Performance (IEC Compliant)
Driver failure rate at 7000 h 0.5 %
Useful life L80B10 100000 h
Lumen maintenance at useful life of 100000 h,at 25 °C
Application Conditions
Ambient temperature range -30 to +45 °C
Dimensional drawing
Installation & Mounted and package list
Photometric data
