High Power AC 240v 45 Degree 50 Watt LED SMD Flood Light
LEDs chip 5050 waterproof IP65 50W Asymmetric len 45 degree LED SMD
Flood Light
LED Flood Lights
Find high-quality Led flood light from LCD. Contact us for
preferential price from leading led flood light manufacturer in
China. LED Flood Light is designed for outdoor and indoor lighting
purpose, and helps to improve visibility, enhance safety, and cut
down energy consumption. Innovations and leading technologies can
always be found in every of the flood lights, and that’s exactly
what forms their unrivaled performance. Choose from LCD portfolios,
light better, save remarkably, and enjoy the great durability.
Features:
• Modern slimline design
• Low energy costs
• Long lasting LED
• High Power
Specifications:
Input Voltage: 240v AC
Power (w): 10W, 30W, 50W
Material: Die cast aluminium
Colour: Black
IP Rating (IP): IP65
Colour Temperature: 4000k
Lumens (lm): 850lm*, 2550lm*, 4250lm*
CRI: >80
Beam Angle: 120°
Dimmable: No
Lamp Base: Buit in SMD LED
Warranty: 5 years replacement**
FS Family
| Item | 10W | 20W | 30W | 50W | 80W | 100W | 150W | 200W |
| Input Voltage | 90-265VAC or 12-28VDC |
| Input Current | 0.05A | 0.1A | 0.15A | 0.23A | 0.38A | 0.48A | 0.7A | 0.93A |
| Power Efficiency | >89% | >89% | >89% | >95% | >97% | >97% | >97% | >97% |
| LED Consumption | 9W | 18W | 27W | 45W | 72W | 91W | 135W | 185W |
| System Consumption | 10W | 20W | 30W | 50W | 80W | 100W | 150W | 200W |
| Power Factor | >0.95 |
| Total Harmonic Distortion | THD< 20% |
| Dimmable | 1-10V , DALI ,Triac on requests |
| Power Line | 1.0m㎡three line |
| Chip Brand | LUMILEDs/CREE/Bridgelux / OSRAM (SMD3030) / SMD5050 on requests |
| LED Encapsulation | 12LEDs | 24LEDs | 36LEDs | 60LEDs | 96LEDs | 120LEDs | 180LEDs | 240LEDs |
| Rated LED Efficacy | 160-180 lumen/w |
| Luminous Efficiency | 130-160 lumen/w |
| Color Temperature | 3000K / 4000K / 6500K |
| Luminous Output | 1350lm | 2700lm | 4050lm | 6750lm | 10800lm | 13500lm | 20250lm | 27000lm |
| CRI | Ra> 80 |
| SCDM | SDCM <5 |
| Lumen Maintenance | > 80%@50,000h |
Product cut sheet
Operating and Electrical
Input Voltage 100 to 277 VAC or 12-28 VDC
Input Frequency 50 to 60 Hz
Inrush current 340 A
Inrush time 0.025 ms
Power Factor (Min) >0.95
Controls and Dimming
Dimmable on requests 1-10V , DALI , Triac
Mechanical and Housing
Housing Material Aluminum die-cast 6063
Reflector material Polish Aluminum
Optic material Acrylate
Optical cover 4mm temper Glass
Fixation material corrosion resistant powder coating carbon Steel
Mounting device Mounting bracket adjustable
Optical cover Flat
Optical cover Clear
Over Time Performance (IEC Compliant)
Driver failure rate at 7000 h 0.5 %
Useful life L80B10 100000 h
Lumen maintenance at useful life of 100000 h,at 25 °C
Application Conditions
Ambient temperature range -30 to +45 °C
Installation & Mounted and package list
