4000 K Pure White 250 Watt Ocean Led Underwater Lights
led security flood light 250 watt optic beam 120 degree AC90-305V
40000lm IP67
Specifications
| No. | Name | flood light 250 watt |
| 1 | Model | LCD-FA-205 |
| 2 | Power | 250W |
| 3 | CCT | 3000K/4000K/5000K/6000K |
| 4 | Beam angle | 25° 40° 60° 90° |
| 5 | Chip brand | Bridgelux 5050 |
| 6 | CRI | >70 |
| 7 | Efficiency | 160Lm/W |
| 8 | Lumen | 40000lm |
| 9 | IP Rate | IP67 |
| 10 | Working voltage | 90-305V |
| 11 | Working temperature | -40℃~50℃,20%~90% H.R |
| 12 | Storage temperature | -40℃~85℃10%~90% H.R. |
| 13 | Power efficiency | 93% |
| 14 | PF | >0.98 |
| 15 | Lifespan | 50000H |
| 16 | Housing material | Aluminum alloy |
Driver features
• Electronic dimmable driver: Dali, Traci
• Minimum dimming level: 1-10V
Structures and materials (HOUSING AND FINISH)
• Housing material:die-cast and sheet metal aluminium
body,stainless steel screws and brackets
• Housing surface finish:polyester powder coat
• Standard colour(s):black RAL9007
• Optic:UV protected Polycarbonate lens
• Protector:tempered low-iron glass
• Tightness level:IP67
• Impact resistance:IK 08
• All materials used in this product are CE and ROHS compatible.
ELECTRICAL INFORMATION
Input voltage and frequency: 100-277VAC, 50-60Hz
• Electrical Class I EU
• Power factor >0.95
• Surge protection options (kV): 2KV / 4KV / 6KV
• Electromagnetic compatibility (EMC):EN 55015:2013/A1:2015, EN
61000-3-2:2014, EN 61000-3-3:2013, EN 61547:2009, EN 62493:2015
• Control protocol(s) :1-10V, DALI
Standards and regulation
CE, Directive 2014/30/EU, 2014/35/EU ,2009/125/EC
1194/2012/EU, 2011/65/EU, EN 60598, EN 62471, EN 55015,
EN 61000-3-2, EN 61000-3-3, EN 62493, EN 61547.
Other options available
Optional precabling
Other RAL colours available on request
Product DIMENSIONS
| Item Name | AxBxC (MM) |
| FA-085/105/153 IP67 flood light | 389.2x296.7x57 |
| FA-205 IP67 flood light | 436.6x345.7x57 |
| FA-255 IP67 flood light | 436.6x345.7x57 |
| FA-305/353 IP67 flood light | 582x385x60 |
Weight (kg ):
| Item Name | Weight (KG) |
| FA-085/105/153 IP67 flood light | 3.4 |
| FA-205 IP67 flood light | 4.8 |
| FA-255 IP67 flood light | 7.2 |
| FA-305/353 IP67 flood light | 7.5 |
Product Construction
Product Photos
